Installation manual

HB-37350-810-01-50F-EN PSC1-C-10 Installation manual V2.1.docx Page 113 of 189

Version: 50F

Terminal assignment

Unit

Terminal

Description

Note

CPU

X13

1 – NC

No function

2 – NC

3 – T0

Pulse outputs

4 – T1

X14

1 – I 00

Safe digital inputs

2 – I 01

3 – I 02

4 – I 03

X23

1 – I 04

2 – I 05

3 – I 06

4 – I 07

X24

1 – I 08

2 – I 09

3 – I 10

4 – I 11
