schmersal PSC1-C-10 Series User Manual

Installation manual
HB-37350-810-01-50F-EN PSC1-C-10 Installation manual V2.1.docx Page 35 of 189
Version: 50F
Environmental data
Temperature
0°C … +50°C operation
-25C° … +70C° storage, transport
Degree of protection
IP 20
Climatic class
3k3 according to DIN 60 721-3
Minimum, maximum relative
humidity (no condensation)
5% - 85%
EMC
EN 61000-6-2, EN 61000-6-4, EN 61000-6-7,
EN 61800-3, EN 61326-3, EN 62061
Use of operating equipment
2000m
Overvoltage category
III
Level of contamination
2
Mechanical data
Size (HxDxW [mm])
PSC1-E-37 = 100x115x67,5
Weight
PSC1-E-37 = 400 g
Attachment
Can be snapped to DIN rail
Min. connection cross-section / AWG
0.2 mm² / 24
Max. connection cross-section / AWG
2.5 mm² / 12
Options:
**
pn/pp can be configured via SafePLC2
***
Derating, see section "Derating of outputs"
1)
Value only applies for expansion module. For an overall assessment according to EN 13849
a series connection with the related basic device is to be used
=> PFH
Logic
= PFH
Basic
+ PFH
Expansion
+ PFH
SDDC/SMMC
Note:
If the network architecture consists of only one basic module and decentralised I/O modules, a
PFH
SDDC
value of 2.2 *10
-9
must be added.
In this context, the number of decentralised I/O modules has no influence on the PFD value.
If the network architecture consists of several basic modules and decentralised I/O modules, a
PFH
SDDC/SMMC
value of 3.2 *10
-9
must be added.
