schmersal PSC1-C-10 Series User Manual

Installation manual
HB-37350-810-01-50F-EN PSC1-C-10 Installation manual V2.1.docx Page 61 of 189
Version: 50F
Type
Encoder on
interface
X1/2
Type
Encoder on
Interface
X3/4
(on request)
Type
Encoder on
X 23
Input
(I04…I07)
Safe
speed
Safe
direction
Safe
positio
n
Fault exclusion
DC
1-channel
sub-system
2-channel
sub-system
dynamic
2-channel
sub-system
non-
dynamic
(standstill
monitoring)
NC
NC
1 x proximity
switch
+
1 x proximity
switch
X
Fault exclusion mech. shaft fracture, positive
locking encoder shaft connection required if
common element in the take-off, protected cable
laying
n.a.
99%
80-90%
NC
NC
2 x proximity
switch 90°
+
2x proximity
switch 90°
X
X
X
Fault exclusion mech. shaft fracture, positive
locking encoder shaft connection, required if
common element in the take-off, protected cable
laying,
DC values only with 2x 2x 3-wire proximity switch
n.a.
99%
99%
Incremental
NC
NC
X
Fault exclusion mech. shaft fracture, positive
locking encoder shaft connection required
60%
99%
80-90%
Incremental
Incremental
NC
X
X
n.a.
99%
95%
