Installation manual
HB-37350-810-01-50F-EN PSC1-C-10 Installation manual V2.1.docx Page 92 of 189
Version: 50F
4.3.5.2.5 Redundant dual-channel output
Suitable for PL d or higher according to EN ISO 13849-1. Usage of two outputs IQQx in
conjunction with a dual-channel external circuit.
4.3.5.2.5.1 Dual-channel circuit in same group
IQQ00
X12
X21
IQQ01
T0
T1
L+
L-
IQQ02
IQQ03
IQQ04
IQQ05
IQQ06
IQQ07
IQQ08
IQQ09
X22
Redundant dual-channel outputs in same group in conjunction with dual-channel shutdown circuit
