5200 Multi Purpose and 5200 Multi Purpose HF Gas Analysers
05230001A / Revision 976
APPENDIX
A1 DATA LOG OUTPUT FORMATS
The data log is output in the form of an identifier line, followed by a number of log lines,
one line for each entry stored in the data log.
The identifier line is in the form: "Servomex <serial number> ; <gas>", where <serial
number> is the Multi Purpose serial number as shown on the Information screen (see
Figure 7) and <gas> is as specified below.
Each log line consists of a number of elements, separated from each other by the
delimiter string " ; " (space, semicolon, space), in the following format:
<log id> ; <date> ; <t
ime> ; <gas> ; <measureme
nt> ; <units> ; <alarm status>
; <fault
stat
us>
[ ; <gas> ; <measurement> ; <units> ; <alarm status> ; <fault status>]
where:
<log id> Is in the form "X.Y", where "X" is a digit (or digits) specifying
the batch number and "Y" is a digit (or digits) specifying the
number of the measurement within the batch.
<date> Is the date on which the data log entry was made.
<time> Is the time at which the data log entry was made.
<gas> Specifies the sample gas measured.
<measurement> Is the actual sample measurement as displayed on the
measurement screen.
<units> Is the measurement units, as displayed on the measurement
screen.
<alarm status> Is either blank (not output), or "Alarm" if a measurement
alarm condition existed when the log entry was made.
<fault status> Is either blank (not output), or "Fault" if a fault condition
existed when the log entry was made.
"[" and "]" Elements between these bracket symbols are only output
when the Multi Purpose is configured for two sample
measurements. The bracket symbols themselves do not
appear in the output.
