Servomex SERVOFLEX MiniMP User Manual

5200 Multi Purpose and 5200 Multi Purpose HF Gas Analysers
05230001A / Revision 984
APPENDIX
A6 OPTIONAL FLOWMETERS
A6.1 Overview
Two optional flowmeters are available for the Multi Purpose, as follows:
• The unvalved flowmeter, for use with a standard Multi Purpose without an internal
sample pump. This flowmeter shows the flow rate of sample gas or calibration gas
into the Multi Purpose.
• The flowmeter with a flow control valve, for use with a Multi Purpose HF or a
standard Multi Purpose with an internal sample pump. This flowmeter shows (and
allows you to control) the flow rate of sample gas or calibration gas into the Multi
Purpose.
A6.2 Specification
A6.3 Preparing the Multi Purpose with a flowmeter
If you have ordered the flowmeter option, the flowmeter will be supplied fitted to the
side of the Multi Purpose, as shown in Figure A2.
Before you use the Multi Purpose, ensure that the inlet pipe (2) is correctly fitted
between the flowmeter outlet and the sample gas inlet on the front of the Multi
Purpose. If the pipe is not already fitted:
1. Remove the protective plastic cover from the flowmeter outlet.
2. Remove the protective plastic cover from the sample gas inlet on the front of the
Multi Purpose (Figure 1, item 8).
3. Fit the inlet pipe supplied between the flowmeter outlet and the sample gas inlet
on the front of the Multi Purpose.
Flowmeter indicated flow rate range
Standard Multi Purpose without sample pump 1 to 10 l min
-1
*
Standard Multi Purpose with sample pump 100 to 1000 cm
3
min
-1
†
Multi Purpose HF 200 to 2500 cm
3
min
-1
#
* Equivalent to a flow rate range of 0.035 to 0.35 ft
3
min
-1
.
† Equivalent to a flow rate range of 100 to 1000 ml min
-1
(0.0035 to 0.035 ft
3
min
-1
).
# Equivalent to a flow rate range of 0.2 to 2.5 l min
-1
(0.007 to 0.087 ft
3
min
-1
).
