5200 Multi Purpose and 5200 Multi Purpose HF Gas Analysers
05230001A / Revision 96
2.2 Sample gas
WARNING
If you sample carbon monoxide, the quantity of gas sampled by the
Multi Purpose may be above the short term exposure limit for carbon
monoxide, and so the sample should be considered to be toxic. Similarly,
other sample and calibration gases which you use may also be
considered as toxic. You must therefore carry out your own risk
assessment before you use the Multi Purpose with such gases. The
maximum inlet pressure of such toxic gases is
34.5 kPa gauge (5 psig, 0.35 bar gauge).
Pressure range
without internal sample pump
(see WARNING above)
6.9 to 68.9 kPa gauge
(1 to 10 psig)
(0.07 to 0.69 bar gauge)
with internal sample pump -3.4 to 3.4 kPa gauge (max)
(-0.5 to 0.5 psig)
(-0.03 to 0.03 bar gauge)
Dew point Less than (ambient temperature minus 10
o
C)
Less than (ambient temperature minus 50
o
F)
Particulate size Less than 2 μm
