5200 Multi Purpose and 5200 Multi Purpose HF Gas Analysers
05230001A / Revision 9
23
4.10 Editing on-screen data
A common method is used for editing data shown on all of the different screens.
When you press the soft key to edit an item of data, the screen changes to show
the corresponding edit screen, with the first digit highlighted; a typical edit screen is
shown in Figure 8:
Figure 8 - A typical edit screen
When the first digit is highlighted, press the soft key to exit the menu without
changing the data.
Alternatively, use the soft keys to edit the data as follows:
Note that the figures above and below the highlighted digit show the digits above and
below the currently highlighted value.
When the last digit is highlighted, press the soft key to enter the new data.
Soft key Function
Increases the highlighted digit by 1.
Decreases the highlighted digit by 1.
Moves the cursor left to the previous digit.
Moves the cursor right to the next digit.
+
When editing numerical values, the decimal point appears between digits
"9" and "0".
