5200 Multi Purpose and 5200 Multi Purpose HF Gas Analysers
05230001A / Revision 9
79
APPENDIX
A3 PRINTER OUTPUT FORMATS
If you have selected printed outputs (see Section 6.7.1), each time you press the
soft key, a single sample measurement report is printed (on the Servomex supplied
printer). The format of this report is as shown below:
where:
Date: <date>
Time: <time>
I.D.: <serial number>
Batch:
Product:
Measurement:
1
<gas>
XXXX <units>
<alarm>
2
<gas>
XXXX <units>
<alarm>
Signature
<date> Is the date on which the report was printed, in the currently
selected format (see Section 5.3.2).
<time> Is the time at which the report was printed, in the format
hh:mm:ss (hours:minutes:seconds).
<serial number> Is the serial number of the Multi Purpose.
1 <gas> Specifies transducer 1 and the sample gas measured.
2 <gas> Specifies transducer 2 and the sample gas measured.
+
This complete line is shown blank on the printer output
for a 1-measurement Multi Purpose.
XXXX Is the sample measurement.
<units> Is the measurement units, as displayed on the measurement
screen.
To Next Page
