4.3 Soft key legends
The four soft key legends at the bottom of the Measurement screen (Figure 3)
correspond to the four soft keys on the front of the Multi Purpose. (The first legend
corresponds to the function of soft key 1, the second legend corresponds to the
function of soft key 2, and so on).
On the Measurement screen, the soft key functions are as follows:
+
During normal Multi Purpose operation, the software health indicator
continuously moves from left to right and then back again, below the status
icon bar. If the indicator stops moving, this means that the Multi Purpose is
not operating correctly, and you must refer to Section 8.
+
If no soft key is pressed for 10 minutes, the Measurement screen will be
automatically displayed. (You will also then have to enter the password again
to access any password-protected screens: refer to Figure 4 and to
Section 4.6.)
Legend Meaning Function (when soft key pressed)
Menu Displays the Menu screen: see Section 4.7.
Calibrate * Displays the Calibrate screen: see Section 6.1.
Alarm * Displays the Alarm option screen: see
Section 6.5.4.
Logging
†
Displays the Data logging screen: see Section 6.7.
Print
†
Produces a printed sample measurement report:
see Section 6.7.9.
* These soft keys are ‘shortcuts’ to these menus, which can also be selected by
pressing the soft key with the corresponding menu option highlighted on
the Menu screen: see Section 4.7.
† If you have selected printed outputs (see Section 6.7.1), the ‘Print’ legend is
shown instead of the ‘Logging’ legend.
