5200 Multi Purpose and 5200 Multi Purpose HF Gas Analysers
05230001A / Revision 924
5 INSTALLATION AND SET-UP
5.1 Installation and switch-on
1. Place the Multi Purpose in a suitable operating location, within easy reach of a
suitable electrical supply outlet.
2. If necessary (if sample or calibration gases are toxic or asphyxiant) or if
required:
• Use quick-connect fittings to connect a suitable sized tube to the sample gas
outlet (on the rear or the front of the Multi Purpose: see Figures 1 and 2).
• Use quick-connect fittings to connect a suitable sized tube to the bypass gas
outlet (if fitted, on the rear of the Multi Purpose: see Figure 2).
WARNING
Ensure that the cables and tubes that you connect to the Multi Purpose
are routed so that they do not present a trip hazard to people.
WARNING
Ensure that the electrical installation of the Multi Purpose and the power
supply unit conforms with all applicable local and national electrical
safety requirements.
WARNING
Sample and calibration gases may be toxic or asphyxiant. Ensure that
the external connections are leak free at full operating pressure before
you use sample or calibration gases.
WARNING
Sample and calibration gases may be toxic or asphyxiant. Ensure that
the Multi Purpose sample, bypass gas and calibration ‘T’ piece (if used)
outlets are vented to an area where they will not be a hazard to people.
WARNING
Sample and calibration gases may be toxic or asphyxiant. To prevent the
build-up of such gases, ensure that the Multi Purpose is only used in a
well-ventilated environment.
CAUTION
Do not use the Multi Purpose in an area subject to high levels of vibration
or sudden jolts. If you do, sample measurements may not be accurate,
or the Multi Purpose may be damaged.
