Other soft key legends which are used on the various screens are as follows:
4.4 Status icon bar
The status icon bar appears on all screens. The icons which can be shown and their
meanings are as follows:
Legend Meaning Function (when soft key pressed)
Back Cancels the current screen and displays the
previous screen in the menu structure.
Accept Accepts the currently selected option or data.
(A new screen may be displayed accordingly.)
Edit Allows the highlighted data to be edited.
Batch Starts a new batch (for data logging).
Up Moves the cursor up a list (or increases a digit
during editing).
Down Moves the cursor down a list (or decreases a
digit during editing).
Left Moves the cursor left.
Right Moves the cursor right.
Icon Meaning
Indicates that a fault has been detected by the
Multi Purpose: refer to Section 8.
Indicates that the audible alarm is disabled:
refer to Section 6.5.5.
*
Battery less than 10% full.
*
Battery 10% to 32% full.
*
Battery 33% to 65% full.
*
Battery 66% to 100% full.
* These icons will only be shown on a Multi Purpose with the optional
rechargeable battery fitted. See Section 5.2 for more information.
+
When the ‘battery less than 10% full’ icon starts to flash, this indicates that
the rechargeable battery is virtually empty. The Multi Purpose will
automatically shut down approximately 15 seconds after the icon starts to
flash.
