5200 Multi Purpose and 5200 Multi Purpose HF Gas Analysers
05230001A / Revision 910
2.6 Performance: industrial oxygen sensor (standard Multi Purpose only)
+
The display indication given below is the default indication. You can
configure the Multi Purpose to provide other display indications (see
Section 6.4).
Display indication Measured volume % oxygen
Full Scale Range 0 to 100% oxygen
Resolution 0.1% oxygen
Linearity ± 0.1% oxygen
Intrinsic error (accuracy) ± 0.1% oxygen
Zero drift per week ± 0.2% oxygen
Output fluctuation ± 0.1% oxygen
Response time
*
Without drying tube
With drying tube fitted
15 seconds
25 seconds
Flow effect
†
± 0.1% oxygen
Zero temperature coefficient ± 0.2% oxygen per 10
o
C (18
o
F)
Span temperature coefficient ± 0.3% oxygen per 10
o
C (18
o
F)
Tilt effects ± 0.15% oxygen per 15
o
of tilt
Pressure effects Directly proportional to ambient barometric
pressure
#
*T
90
at 68.9 kPa gauge (10 psig, 0.69 bar gauge) supply pressure. Response
time will increase if the Multi Purpose has a sample conditioning panel: refer
to Section A7.2.
† Within sample gas supply pressure range specified in Section 2.2.
# A 1% change in ambient barometric pressure will result in a 1% change
in sample reading.
