5200 Multi Purpose and 5200 Multi Purpose HF Gas Analysers
05230001A / Revision 9
85
* Fitted between the flowmeter outlet and the Multi Purpose inlet.
† Only fitted to a valved flowmeter for use with a Multi Purpose HF or a standard Multi
Purpose with an internal sample pump.
Figure A2 - Multi Purpose with a flowmeter
Key Description Key Description
1.
2.
3.
Multi Purpose
Inlet pipe *
Sample gas inlet
4.
5.
6.
Flow control valve
†
Flow indicator
Flowmeter assembly
