SharkRF openSPOT2 - NXDN Radio Setup; P25 Radio Setup; POCSAG Pager Setup

TakealookattheWires-XbuttonusagedescriptionandtheC4FM/FusionAPRSpageifyouwanttoforwardyour
transceiver'sGPSpositiontotheAPRSnetwork.
NXDNradiosetup
Setupasimplexchannel(withthesameRXandTXfrequencies).
Setthechannel'sRadioAccessNumber(RAN)totheopenSPOT2'sRAN(bydefaultit's0,itcanbechanged
ontheSettingspage,NXDNsettingssection).
CreateacontactwithprivatecalltoID9999,whichistheopenSPOT2'sbuilt-inlocalechoservice.Makea
calltothisIDtotesttheconnectionbetweenthetransceiverandtheopenSPOT2.
RunAutoCalincaseyouhavevoicequalityissues.SeetheAutoCal'susagedescriptionintheConnectors
sectionbelow.
P25radiosetup
Setupasimplexchannel(withthesameRXandTXfrequencies).
Setthechannel'sNetworkAccessCode(NAC)totheopenSPOT2'sNAC(bydefaultit's0,itcanbechanged
ontheSettingspage,P25settingssection).NotethattheopenSPOT2requirestheNACindecimalformat
(example:ifyouhavetheNAC0x293inyourradiothenyouhavetoenter659intheopenSPOT2).
CreateacontactwithprivatecalltoID9999,whichistheopenSPOT2'sbuilt-inlocalechoservice.Makea
calltothisIDtotesttheconnectionbetweenthetransceiverandtheopenSPOT2.
RunAutoCalincaseyouhavevoicequalityissues.SeetheAutoCal'susagedescriptionintheConnectors
sectionbelow.
POCSAGpagersetup
Makesureyousettheyourpager'sreceivefrequencytotheopenSPOT2'sPOCSAGfrequency,andthatthe
baudratesmatch.Polarityshouldbenormal.TheopenSPOT2'sPOCSAGfrequencyandothersettingscanbe
changedontheSettingspage,POCSAGsettingssection.
MakesureyousettheRIC(s)inyourpager'sconfigurationtotheaddress(es)youwanttoreceivemessages
on.
SeetheDAPNETWikiformoreinformationaboutPOCSAGandDAPNET.
Settingupyourtransceiver
12
