Sharp VL-PD6H User Manual

Advanced Features
Recording
Advanced
Features
55
Using the Zoom Microphone
(Optional Accessory)
With the optional zoom microphone, you can
record audio according to the magnification of
the zoom lens for producing the optimum
sound. You can also set the zoom microphone
to record only sounds at a distance.
Mounting the Zoom Microphone
1 Align the mounting pin of the zoom
microphone with the mounting hole on
the camcorder, and slide the zoom
microphone in the direction of the arrow
until it locks into place.
Selecting Zoom Microphone Mode
Select a Zoom Microphone mode option when
the zoom microphone is mounted.
Zoom Microphone mode options
AUTO: The camcorder automatically selects
the optimum sound according to the
magnification of the zoom lens. When the
zoom lens is at a wide-angle setting, the built-
in microphone is used to record sounds. As
the zoom magnification increases, the sounds
from the zoom microphone and built-in
microphone are mixed according to the zoom
setting.
TELE: The zoom microphone is fixed to record
sounds at a distance. (The built-in
microphone is turned off.)
OFF: The zoom microphone is turned off. (The
built-in microphone is on.)
1 Mount the zoom microphone to the
camcorder.
2 Set the camcorder to Tape Recording
mode.
3 Press the MENU/DISPLAY button until
the menu screen appears.
4 Turn the SET-PUSH dial (Q) to select
“ZOOM MIC”, and then press the dial
(W) to select the desired zoom
microphone mode.
REMOTE
ZOOM MI C
MI C LEVEL
AUD I O MOD E
END
[
MENU/DISPLAY
]
AUTO
OFF
12BI T
ON
M ENUAUTO
AUTO
----------- 4 ----------
W IND
Q
W
PUSH
AUTO TEL OFFE
5 Press the MENU/DISPLAY button to
turn off the menu screen.
Notes:
• Before recording an actual event, test the
camcorder to check how the sound is recorded.
• When the camcorder is in Easy mode, the Zoom
Microphone mode is fixed to “AUTO” and cannot
be selected on the menu screen.
• You can adjust the sound input level of the zoom
microphone and the built-in microphone to the
desired setting (see page 56).
Mounting hole
Mounting pin
Screw
2 Turn the screw in the direction of the
arrow to secure the zoom microphone.
Removing the zoom microphone
Turn the screw in the opposite direction than
when mounting, and then pull off the zoom
microphone.
Cautions:
• Use the zoom microphone with the windscreen
left on. Taking the windscreen off will significantly
increase the volume of wind and other
background sounds.
• Do not pick up the camcorder by the zoom
microphone, as this may cause the camcorder
or zoom microphone to break down.
VL-PD6H/048-059 01.4.24, 0:19 PM55
