SmartMedia Card
Features
70
4 Close the card slot door.
Inserting and Removing a
SmartMedia Card
Inserting a SmartMedia Card
1 Make sure that the Power switch is set
to OFF.
2 Slide the card slot door release in the
direction of the arrow.
• The card slot door is opened.
3 Insert a SmartMedia card into the slot
with the contact area facing in and with
the chipped corner facing down, and
push it in as far as it will go.
Card slot door
release
SmartMedia Card Features
Recording
Removing a SmartMedia Card
Perform steps 1 and 2 of “Inserting a
SmartMedia Card”, and then pull the
SmartMedia card straight out.
Note:
• The supplied SmartMedia card has been
formatted and can be used immediately.
Contact area
Chipped
corner
VL-PD6H/070-074 01.4.24, 0:58 PM70
