47
© 2012 SHFL entertainment, Inc.
MD2® CR
Service Manual 20121015
Confidential
OR
Fifty three cards, with the Joker, stacked face down, in the following
order:
10. Press the GREEN button to raise the Platform.
11. Load the requested number of cards face down. The Ace of Spades is
the first card on the bottom of the stack that is loaded into the
shuffler.
12. Press the GREEN button to lower the Platform.
13. The shuffler display will list a series of events on the message panel
while the card tuning process is performed.
14. When the process is complete, the message panel will display:
15. Press the GREEN button to raise the Elevator
16. The message panel will display:
17. then
Remove Cards
Tune Completed
Push GREEN Button
Tuning……. xx% Done
( 52 Cards )
Please Wait, or if Ready
Push GREEN Button
J
O
K
E
R
JOKE
R
To Next Page
