Sensor & Button Faults (Cont’d)
Symptom Cause Remedy
Display shows “Remove Cards”
when machine is empty.
Faulty FCPS, CIS, COS,
PCPS
Clean or replace the faulty
sensor element or Harness
Shuffler stops but display shows
“shuffling”.
Faulty Card Out Sensor
Replace the faulty CO sensor
element (#38 & #40)
Card Rec failure (intermittent
partial card feed).
Camera Ribbon Cable is
not seated properly
Re-seat or replace the Camera
Ribbon Cable
Loose or faulty Camera
Trigger Sensor
Re-seat or replace the CTS
switch element (#36)
Initializes. After cards are
inserted, display shows “Check
Tower Sensor”
.
Faulty Tower Down Switch Replace the TDS switch (#34)
Tuning
Symptom Cause Remedy
Display shows “Deck not
Tuned”.
Deck is not tuned
Tune deck ‘Tune Cards’ in
Setup mode
Invalid deck message after
successful tune.
Poorly tuned images
View Images web page
Focus camera and retune card
deck
Incorrect deck selected for
tuning
Assure that the correct deck
type and description are
selected in the shuffler
Images shifted. Debris on calibration plate
Remove and clean underside
of calibration plate. Replace
plate
Debris on or damage to
the camera lens
Clean camera lens or replace
the camera
Incorrect deck selected for
tuning
Assure that the correct deck
type and description are
selected in the shuffler and
Deck Library web page
