Insert the decks and push the GREEN button to lower the Elevator and
begin verification.
When verification is complete, the message panel will display:
Step By Step Mode
This menu item allows single stepping through the shuffle each time the
GREEN button is pressed. Push the RED button to enter this mode.
Pressing the RED button will single step the shuffle one card at a time.
Aborting the Shuffle
To abort the Step by Step mode, turn shuffler power off and restart.
Sensors
This menu item identifies the state of the inputs (switches and sensors).
Position 1 starts at the left.
* In this example, positions 9, 11 and 13 are identified with a “1”.
Position Sensor/Switch Description
1 CIS Card In Sensor
2 COS Card Out Sensor
3 FCPS Feeder Card Present Sensor
4 FCOS Feeder Card Out Sensor
5 PCPS Platform Card Present Sensor
6 PHS Platform Home Switch
7 GHS Gripper Home Switch
Run Step By Step Mode
Sensors:
000 000 001 010 10 *
Shuffling
Gripped: 2, Shuffled: 5
Verification Complete
Push GREEN Button
