7.0 Machine Switch Locations
Switches and Sensors
LED Indicator Location
Name Description Module #1 Module #2 Plug #
PHS Platform Home Switch D7 - 2
ENC Encoder - - 3
GCPS Gripper Card Present Sensor D21&D24 - 4
PCPS Platform Card Present Sensor - D3 6
CDS Card Drop Sensor - - 28
GS Green Switch D22 - 20
RS Red Switch - D4 22
FCPS Feeder Card Present Sensor - D2 23
FCOS Feeder Card Out Sensor - D6&D9 24
GHS Gripper Home Switch - D7 25
GWS Gripper Working Switch - D24 26
LED BRD Camera LED Source 27
TDS Tower Down Switch D4 - 31
FEUS Feeder Elevator Up Switch D3 - 33
FEHS Feeder Elevator Home Switch D23 - 34
FAN Camera Fan Source 35
CTST Camera Trigger Switch
Transmitter
36
CIST Card In Sensor Transmitter - - 37
COST Card Out Sensor Transmitter - - 38
CISR Card In Sensor Receiver - D22 39
COSR Card Out Sensor Receiver - D5&D9 40
CTSR
Camera Trigger Switch
Receiver 54
Motors
Name Description Module #1 Module #2 Plug #
FEM Feeder Elevator Motor X 10
PM Platform Motor X 11
POM Pick Off Motor X 17
SUM Speed Up Motor X 18
GM Gripper Motor X 19
