Platform / Grippers (Cont’d)
Symptom Cause Remedy
Machine frequently goes into
Auto-Setup (cards falling out of
Gripper)
.
Loose Gripper Belt Adjust the Gripper Belt
Gripper blocks are worn Replace both Gripper Blocks
Broken Compression
Spring on Gripper
Assembly
Replace the Spring
Dirty or Faulty PCPS Replace the PCPS (#6)
Motor Faults
Symptom Cause Remedy
Fan Motor does not operate. Faulty Fan Motor
Replace Fan Motor Assembly
(#15)
Camera Blower Motor does not
operate.
Faulty Camera Blower
Motor
Replace Camera Blower Motor
(#35)
Platform rises and falls Cards
will not feed.
Faulty Speed Up Motor Replace Speed Up Motor (#18)
Sensor & Button Faults
Symptom Cause Remedy
Display shows “Remove Cards”
when machine is empty.
Dirty or faulty FCPS, CIS,
COS, PCPS
Clean or replace the faulty
sensor element
Faulty I/O Board Replace I/O Board
Display shows "Remove Feeder
Cards" when feeder is empty.
Dirty, faulty or
misadjusted FCPS
Clean or replace the FCPS
(#23)
Display shows “Card Jam” when
all cards are removed.
Faulty CIS, COS or FCOS
Clean or replace the faulty
sensor element
Display shows Push GREEN
Button - “Load Cards“.
Faulty GREEN Button
Replace the GREEN Button
(#20)
Faulty Platform Card
Present Sensor
Clean or replace the PCPS, or
#6 Harness
GREEN Button is inactive when
requested.
Faulty GREEN Button
Replace the GREEN Button
(#20)
RED Button is inactive when
requested.
Faulty RED Button Replace the RED Button (#22)
Auto-setup will not complete.
Gripper Card Present
Sensor not sensing
bottom card in Gripper
Adjust the GCPS to aim at
bottom card when gripper
separates the stack of cards
Platform jams after 10 cards are
shuffled.
Faulty Gripper Card
Present Sensor
Clean or replace the GCPS
(#4)
