Speed Up (Cont’d)
Symptom Cause Remedy
Speed Up Rollers pause after
each card is inserted, slow
shuffle.
Debris around speed up
shaft blocking CIS/COS
Remove debris from the shaft
Faulty Card In/Card Out
Replace the faulty CI/CO
sensor element (#37 & #39 or
#38 & #40)
Speed Up Rollers pause after
each card is inserted; slow
shuffle
.
Debris around speed up
shaft blocking CIS/COS
Remove debris from the shaft
Faulty Card In Sensor
Replace the faulty CI sensor
element (#37 & #39)
Speed Up Motor stalls.
Speed Up Rollers are
swollen
Replace the Speed Up Rollers
Platform / Grippers
Symptom Cause Remedy
The Platform is continually re-
homing. Cards do not move
from Feeder.
Faulty or loose Encoder
Replace the Encoder, or #3
Harness
Loose Encoder Coupling
Tighten the Coupling between
the Platform Motor and the
Encoder
Broken Encoder Coupling Replace broken Coupling
Platform Belt is loose
Check and adjust the belt for
proper tension
Platform tower popping up while
shuffling.
Felt or debris buildup
between bearing housings
on Platform and Tower
Linear Guides
Blow out / Clean out debris
Platform lowers before dealer
can remove shuffled cards.
Unload Delay time set too
short
Increase Unload Delay time in
the Setup menu
Platform elevator rises. Display
shows “Remove Cards”.
Faulty Platform Card
Present Sensor
Replace the PCPS, or Retractile
Cord Assembly (#6)
Platform jams after 10 cards are
shuffled.
Dirty or faulty Gripper
Card Present Sensor
Clean or replace GCPS Sensor
Gripper cannot move to “Home”
position.
Faulty Gripper Home
Switch
Replace the Gripper Home
Switch (#25)
Gripper Homing Jam. Faulty Gripper Motor
Replace the Gripper Motor
(#19)
Grippers fail.
Display shows “Platform Jam Or
Service Required”.
Faulty Gripper Card
Present Sensor
Replace the GCPS (#4)
