Mounting
6.4.3 Fastening with floor stands
Floor stands are suitable for mounting the C4000 horizontally. Depending on the mounting
method, in this way you can realise mounting heights from 70 to 430 or 519 to 780 mm.
Fig.
46
:
Mounting with floor
stands
519
780
70
430
Part no. 2041661
