Operating Instructions Chapter 12
C4000 Palletizer Std./Adv.
C4000 Fusion
8012249/YT69/2016-02-25 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 99
Subject to change without notice
Technical specifications
Minimum Typical Maximum
Operating data
Connection Hirschmann plug M26× 11 + FE
Cable length
2
1)
50 m
Wire cross-section 0.75 mm²
Ambient operating temperature 0 °C +55 °C
Air humidity (non-condensing) 15% 95%
Storage temperature –25°C +70 °C
Housing cross section 40 mm × 48 mm
Vibration resistance 5 g, 10E55 Hz (EN 60068E2E6)
Shock resistance 10 g, 16 ms (EN 60068E2E29)
12.2 Response time
The response time depends on the following parameters:
number of beams
beam coding
multiple sampling
How to determine the response time of the system:
Read the response times of the C4000 (shown on type label). Note whether the system
is operated with or without beam coding.
If you are planning the application without actually having any devices available, you may
also determine the response time using Tab. 26 and Tab. 27.
For information on the number of beams see Tab. 26.
Then see Tab. 27 for information on the response time.
Number of beams Protective field height
[mm]
20 mm 30 mm 40 mm
300 30 15 10
450 45 23 15
600 60 30 20
750 75 38 25
900 90 45 30
1050 105 53 35
1200 120 60 40
1350 135 68 45
1500 150 75 50
1650 165 83 55
1800 180 90 60
For information on the response time see Tab. 27 on page 100.
21)
Depending on load, power supply and cable cross-section. The technical specifications must be observed.
Note
depending on the protective
field length and the physical
resolution
