SICK C4000 Fusion

Chapter 11 Operating Instructions
C4000 Palletizer Std./Adv.
C4000 Fusion
92 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 8012249/YT69/2016-02-25
Subject to change without notice
Fault diagnosis
11.4 Error displays of the 7Lsegment display
This section explains the meaning of the error displays of the 7Esegment display and how
to respond to the messages. Please refer to chapter 3.3 “Status indicators” on page 24 for
a description of the 7Esegment display.
Display Possible cause Rectification of the error
,  or

Inadequate alignment  Re-align sender and receiver (see page 83).
The display goes off after 2 minutes.
 Configuration
incomplete
 The display goes off automatically once the
configuration has been successfully transferred.
If the display  does not go off:
 Check the configuration of the system using the
CDS (Configuration & Diagnostic Software).
 Re-transfer the corrected configuration to the
system.

or

EDM error  Check the contactors and their wiring, eliminate
any wiring errors, if necessary.
 If  is displayed, switch the device off and back
on again.
 Fault in the reset
button or in its
operation
 Check the reset button for correct function. The
button may be defective or stuck.
 Check whether the reset button has been
pressed, before reset was required.
 Check the wiring of the reset button for any
short-circuit to 24 V.
 The configuration of
the connected
switching amplifier
(e.g. UE402) is
incorrect
 Configure the switching amplifier connected with
the aid of the CDS.
 Check the connection from the C4000 to the
switching amplifier.
 Several operating
modes configured, but
none selected
 Check the connection and the function of the
operating mode selector switch.
 Check the connection for the operating mode
selector switch on the switching amplifier.
 Several operating
modes selected
simultaneously
 Check the connection and the function of the
operating mode selector switch.
 Check the connection for the operating mode
selector switch on the switching amplifier for a
short-circuit.
 Un-configured
operating mode
selected
 Configure the operating mode set on the
operating mode selector switch, or ensure that
this operating mode cannot be selected.
Tab.
24
:
Error displays of the
7Fsegment display
