112 DUSTHUNTER T · Operating Instructions · 8012428 V 2.0 · © SICK MAIHAK GmbH Germany
Specifications
7.2 Dimensions, Part Nos.
All measures are specified in mm.
7.2.1 Sender/receiver unit
Figure 85 Sender/receiver unit DHT-T00
Name Part number
Sender/receiver unit DHT-T00 1043902
225
186
120
105
210
600
388
