Specifications
DUSTHUNTER T · Operating Instructions · 8012428 V 2.0 · © SICK MAIHAK GmbH Germany 113
Figure 86 Sender/receiver unit DHT-T01, DHT-T21
406
241
205
140
104
212
r
=
2
8
0
212
Name Part number
Sender/receiver unit DHT-T10 1043903
Sender/receiver unit DHT-T21 1043904
