Start-up and Parameter Settings
DUSTHUNTER T · Operating Instructions · 8012428 V 2.0 · © SICK MAIHAK GmbH Germany 81
b
Select the "Network Scan Assistant" register, click "Network Scan" and check whether
the set address is displayed.
Figure 67 Network scanning
NOTICE:
During communication on Ethernet disturbances in the data transfer can
appear which are not caused by the measuring system.
b
If measured values are transferred exclusively via Ethernet and used to
control processes, disturbances are possible in the plant operation for
which the manufacturer of the DUSTHUNTER T50/T100/T200 is not
responsible.
Increase the value in field "Scantimeout" from 500 ms to 3000 ms if
disturbances appear in the Ethernet communication.
