An OR operator is applied to the process data for the outputs AUX_OUT of the individual
Fle
xi Loop nodes and the logic states of the parameter AUX_OUT from MSTR AUX_IN.
b
Set the parameter AUX_OUT from MSTR AUX_IN to Off.
b
Save the configuration using Store
9)
.
The output AUX_OUT of the Flexi Loop node is no longer linked to the AUX_IN of
the MSTR2 Flexi Loop accessory.
Flashing mode 1 or 2
Flash modes 1 and 2 can be used to have lamps at the non-safe outputs of the Flexi
Loop nodes flash at a frequency of 1 Hz or 2 Hz.
b
Set the parameter Flashing mode 1 or Flashing mode 2 to On.
b
Save the configuration using Store
9)
.
If the output AUX_OUT of the Flexi Loop node is activated, then it is operated at
1 Hz or 2 Hz.
7.4.2.2 Configuration of the Flexi Loop string
DANGER
Hazar
d due to disabling the protection against tampering!
If you disable the protection against tampering, then a Flexi Loop node can be removed
or jumpered. In this situation the safe sensor cascade switches on despite the change.
Only disable the tamper protection if imperative for the implementation of the applica‐
tion. In this case prevent possible tampering by other measures (e.g. protected cable
laying).
Setting commissioning mode
If necessar
y, deactivate a taught-in configuration by setting the MSTR2 Flexi Loop
accessory to commissioning mode.
b
Log into the configuration software for the standard controller as Specialist.
b
Change to Parameter on the IO-Link port used.
b
Open the Parameter Menu branch there.
The commands and parameters contained in the IODD are displayed.
b
Open the Edit Config. Data branch.
b
Expand the Edit MSTR settings branch.
The system displays the configuration options for the MSTR2 Flexi Loop accessory.
b
On the Commissioning mode menu select the True option.
b
Save the configuration using Store
9)
.
The MSTR2 Flexi Loop accessory changes to the Waiting for configuration mode.
Disabling tamper protection
Define whether the number and types for the Flexi Loop nodes are to be checked on
power up.
b
Open the Edit Config. Data branch.
b
Expand the Edit MSTR settings branch.
The system displays the configuration options for the MSTR2 Flexi Loop accessory.
b
On the Ignore node count menu select the True option.
b
Save the configuration using Store
9)
.
With immediate effect the number of Flexi Loop nodes will not be checked.
b
On the Ignore node types menu select the True option.
9)
Applies f
or TwinCAT™, alternatively Store all User Data (SystemCommand 03h ParamDownloadStart - IO-Link Interface and System Speci‐
fication V.1.1 Table B.9).
7 C
ONFIGURATION
60
O P E R A T I N G I N S T R U C T I O N S | Flexi Loop 8015836/YT10/2016-05-24 | SICK
Subject to change without notice
