10.1.7 MSTR Flexi Loop accessory
FLA-MSTR00001
FL
A-MSTR00002
Test inputs for the Flexi Classic connection layout (FC_A1 and FC_B1)
Input voltage HIGH 13 … 30 V DC
Input voltage LOW –5 … +5 V DC
Input current HIGH 3.5 … 6.2 mA
Input current LOW –2.5 … +2.5 mA
Test outputs for the Flexi Classic connection layout (FC_A2 and FC_B2)
Maximum short-circuit currents 13.5 mA
Table 55: Data sheet MSTR Flexi Loop accessory
Additional data on the variant FLA-MSTR00002 with IO-Link interface
FLA-MSTR00002
General electrical data
Supply voltage (V
S
) on usag
e of IO-
Link
18 … 30 V DC
Non-safe output (C/Q or AUX_OUT)
Type of output Highside driver, short-circuit protected, or IO-Link
Output current Max. 50 mA
Permissible capacitive load Max. 100 nF
Debouncing 100 ms
Non-safe input (AUX_IN)
Logic level switching points
HIGH >13 V/3.5 mA
LOW <5 V/2.5 mA
Maximum input current 6.2 mA
Debouncing 100 ms
Table 56: Additional data on the FLA-MSTR00002 variant
10 TECHNICAL DATA
86
O P E R A T I N G I N S T R U C T I O N S | Flexi Loop 8015836/YT10/2016-05-24 | SICK
Subject to change without notice
