SICK Flexi Loop User Manual

FLN-EMSS1100108
Internal discharging resistance Typical 200 kOhm
Table 50: Additional data on the FLN-EMSS1100108 variant
10.1.4 OSSD Flexi Loop node (FLN-OSSD1000105 and FLN-OSSD1100108)
FLN-OSSD1000105
FLN-OSSD1100108
OSSD inputs
Input voltage HIGH 13 … 30 V DC
Input voltage LOW –5 … +5 V DC
Input current HIGH 3.5 … 6.2 mA
Input current LOW –2.5 … +2.5 mA
Test pulse duration (test spacing)
1)
<1 ms
Discrepancy time monitoring 3 s
Voltage supply for OSSD devices
Supply voltage 16.8 … 30 V DC
Maximum current
FLN-OSSD1000105 at 40 °C 3.9 A
FLN-OSSD1100108 at 40 °C 2 A
FLN-OSSD1000105 at 55 °C 3.1 A
FLN-OSSD1100108 at 55 °C 1.5 A
Non-safe input (AUX_IN)
Logic level switching points
HIGH >13 V/3.5 mA
LOW <5 V/2.5 mA
Maximum input current 6.2 mA
Debouncing 100 ms
Table 51: Data sheet OSSD Flexi Loop node
1)
Is defined by the OSSD device.
Additional data on the 8-pin variant FLN-OSSD1100108
FLN-OSSD1100108
Non-safe output (AUX_OUT)
Type of output Highside driver, short-circuit protected
Output current Max. 500 mA
Permissible capacitive load Max. 1 µF
Internal discharging resistance Typical 200 kOhm
Table 52: Additional data on the FLN-OSSD1100108 variant
10.1.5 Terminator
FLT-TERM00001
Dimensions terminator
(W × H × D)
54 × 13.6 × 13.6 mm
Table 53: Data sheet FLT-TERM00001 terminator
10 TECHNICAL DATA
84
O P E R A T I N G I N S T R U C T I O N S | Flexi Loop 8015836/YT10/2016-05-24 | SICK
Subject to change without notice
