8 FAULT DIAGNOSIS
8017768/12AX/2019-05-31|SICK
OPERATING INSTRUCTIONS | TIC
Subject to change without notice
Recording raw data
You can only activate the function for recording raw data if you are a user with Service
authorization.
1. In the editing mode for the site configuration, log in as a user with Service
authorization.
2. Switch on expert mode.
3. In the navigation tree, go to the level of the relevant system function (not the system
component) and click the Show Details icon.
4. In the detail window for the system function, set the RawDataEnabled parameter to
Yes.
5. Close the detail window and start the configuration.
The raw 2D LiDAR sensor data are then saved inside the /RawData directory on the
Traffic Controller.
