9 Annex
9.1 Technical data
9.1.1 TIC102 data sheet
TIC102 master
TIC102 slave
Features
System part
TIC102
(integrated
evaluation unit)
TIC102 Slave
(without evaluation unit;
must be connected to a
TIC102 Master)
Integrated application
Vehicle classification, traffic counting,
axle counting *
* Another LMS511 SE is required for axle counting.
Scanner version
Two-scanner solution
Vehicle data

Vehicle class (various categorization systems with up
to 30 classes)
 Direction of travel
 Lane assignment
 Confidence level for all vehicle data

Point clouds
Number of lanes covered
1
Recommended distance between
maximum vehicle height and sensor
Typ. 1.5 m
Calibration
Automatic
Laser class
1 eye-safe (IEC 60825-1 (2007-3))
Heating
Yes
Integrated computer unit
Traffic Controller TIC
–
Performance
Counting accuracy
> 99.8%
Classification accuracy
Typ. 98% (for TLS8+1 classes)
Interfaces
Data log

TEMS Info interface
(TCP/IP interface)
 TEMS Manager (HTTP
configuration software)
–
NTP synchronization
Yes
–
Mechanics/electronics
Supply voltage
24 V DC (22.8 V DC ... 25.2 V DC)
Power consumption
130 W, with heating
51 W, without heating
120 W, with heating
41 W, without heating
Dimensions
355 mm x 482 mm x 373 mm
Weight
16.1 kg
15 kg
Mounting position
Above the lane
Installation height
6 m, 5 m ... 8 m
Enclosure rating
IP 66 (EN 60529)
Ambient data
Ambient operating temperature
–20 °C ... +50 °C *
* Protect the TIC102 from direct sunlight with a weather guard
to keep it from overheating.
Tab. 29: TIC102 data sheet
