6.13.2 Using a configuration file to load system parameters
In the following example, the site configuration includes an XML file with the key system
parameters. The system parameters are loaded in TEMS Manager, where they are
subsequently adjusted to the conditions at the measurement site.
When logging in, the user must have Service authorization.
1. In TEMS Manager, click the icon for Load site configuration and start/edit it.
2. Select the configuration file and click Start Configuration.
3. The configuration is loaded in TEMS Manager.
If a configuration is loaded while another configuration is running, the system will
automatically stop the current configuration. The new configuration is loaded and started.
System operation is paused during this process.
Note
