9 ANNEX
184
8017768/12AX/2019-05-31|SICK
OPERATING INSTRUCTIONS | TIC
Subject to change without notice
9.1.2 TIC502 data sheet
TIC502 master
TIC502 slave
Features
System part
TIC502 Master
(with separate evaluation
unit)
TIC502 Slave
(without evaluation unit;
must be connected to a
TIC502 Master or Traffic
Controller TIC via an
Ethernet switch)
Integrated application
Vehicle classification, traffic counting,
speed detection, axle counting *
* Another LMS511 SE is required for axle counting.
Scanner version
Two-scanner solution
Vehicle data
 Vehicle class (various categorization systems with up
to 30 classes)
 Direction of travel
 Speed
 Lane assignment
 Confidence level for all vehicle data

Point clouds
Number of lanes covered
1
Recommended distance between
maximum vehicle height and sensor
Typ. 1.5 m
Calibration
Automatic
Laser class
1 eye-safe (IEC 60825-1 (2007-3))
Heating
Yes
Separate computer unit
Traffic Controller TIC
–
Performance
Counting accuracy
> 99.85%
Classification accuracy
Typ. 98% (for TLS8+1 classes)
Accuracy of speed measurement
± 3 km/h at < 100 km/h
*
± 3% at > 100 km/h
*
Only for vehicles with directional stability which pass under the
LMS Length
Interfaces
Data log

TEMS Info interface
(TCP/IP interface)
 TEMS Manager (HTTP
configuration software)
–
NTP synchronization
Yes
–
Mechanics/electronics
Supply voltage
24 V DC (22.8 V DC ... 25.2 V DC) for the LMS511 2D
LiDAR sensor
24 V DC (12 V DC ... 36 V DC) for the Traffic Controller
Power consumption
120 W, with heating
54 W, without heating
110 W, with heating
44 W, without heating
Dimensions (L x W x H)
498 mm x 411 mm x 191 mm
(only mounting plate with pre-assembled LMS511)
Weight
12.8 kg
12 kg
Mounting position
Above the lane
Installation height
6 m, 5 m ... 8 m
Ambient data
Ambient operating temperature
–40 °C ... +60 °C *
* Protect the TIC502 from direct sunlight with a weather guard
to keep it from overheating.
Tab. 30: TIC502 data sheet
