Dimensions
CNC 61.00 Hardware Description CNC 0610510/12 29
X X30 - power supply (see page 49)
X X31/X32 - ballast resistor (see page 49)
X X50 - internal inputs (see page 51)
X X51 - internal outputs (see page 51)
X X52 - 24 V supply/thermal contact (see page 52)
X X7, X8, X9 - connections to the bus system (see page 46)
X X20 - motor connection (see page 48)
