Functional Description of the Connectors/Interfaces
:
38 Hardware Description CNC 0610510/12 CNC 61.00
Connector Meaning Description
X31/X32 switch-over bridge,
ballast resistor internal / external
page 49
X30 power supply page 49
X50 internal inputs page 51
X51 internal outputs page 51
X52 24 V supply/thermal contact page 52
Connector Meaning Description
X20 motor connection page 48
X7, X8, X9 connectors to the bus system page 46
