Option Modules
CNC 61.00 Hardware Description CNC 0610510/12 87
Software (Example)
The active transducers can be addressed with five system variables.
T_ACT [-2048..2047], T_ACT2 [-2048..2047]
The actual values of the first or second active transducer are provided.
T_Offset [-2048..2047], T_Offset2 [-2048..2047]
These parameters define the offsets for both active transducers. A deviation to the
zero point of the transducer can be compensated by entering the actual converter
value (T_ACTx of the unloaded transducers) into this parameter.
T_ADJ [0..1]
In order to calibrate the active transducers an output (calibrating signal, TTL level)
can be set with this parameter. This parameter applies to both transducers.
