Commissioning
S7-300 Programmable Controller Hardware and Installation
A5E00105492-01
8-5
Module installation and wiring
Points to be examined refer to the
Installation
Manual;
Chapter ...
refer to the
Reference
Manual;
Chapter ...
Are all modules properly inserted and screwed in? 5 -
Are all front connectors properly wired, plugged, screw-
tightened or latched to the correct module?
5; 6 -
Mains voltage
Points to be examined refer to the
Installation
Manual;
Chapter ...
refer to the
Reference
Manual;
Chapter ...
Is the correct mains voltage set for all component? 6 Module Data:
2
Power supply module
Points to be examined refer to the
Installation
Manual;
Chapter ...
refer to the
Reference
Manual;
Chapter ...
Is the mains plug wired correctly? 6 -
Is mains voltage connected? - -
