Installation

S7-300 Programmable Controller Hardware and Installation

A5E00105492-01

5-9

Table 5-4 Slot numbers for S7 modules

Slot number Module Remarks

1 Power supply (PS) –

2CPU–

3 Interface module (IM) To the right of the CPU

4 1st signal module To the right of the CPU or IM

5 2nd signal module –

6 3rd signal module –

7 4th signal module –

8 5th signal module –

9 6th signal module –

10 7th signal module –

11 8th signal module –
