3-27
Operation
Entering a Device Number with the Module
Number
When the System displays the following:
Type In Module & Device: -
Type all of the digits (MMM-DDD),
including leading zeros, and press
ENTER. (When you type the module
number and the device number, use
the Left arrow key as a backspace key
to erase errors.)
The Acknowledge Menu
The Acknowledge menu has four
items from which to choose;
Alarm Supervsry Trouble Security
Use this menu to individually acknowledge
alarms, supervisories, troubles, and
security conditions.
Acknowledge: Alarm
Use this function to individually ac-
knowledge alarms.
If there is no current alarm, the
System briefly displays the following
message and then returns you to the
Acknowledge menu:
No Alarm Exists
(If your System has a printer, it prints
the above message as well.)
If all the alarms are acknowledged,
the System displays the following
message and then returns you to the
Acknowledge menu:
All Alarms Acknowledged
(If your System has a printer, it prints
the above message as well.)
If there is at least one unacknowl-
edged alarm, the menu shows the
most recent unacknowledged alarm on
both lines of the display, as in the
following:
29-041 [custom message]
007 [device type] IN ALR
In the previous display, 29 is the
module number, 041 is the device
number, the message on the first line
is the custom message for the device
at that location, 007 indicates that this
is the seventh alarm, [device type]
indicates the type of device in alarm,
and IN ALR indicates that this is an
alarm.
Press ENTER to acknowledge the
alarm shown.
The System prints a message similar
to the following and removes that alarm
from the unacknowledged alarm list:
ACK Alarm 29-041 16:11:41 Aug 2, 20xx
#7 [custom message], [device type]
In the previous message, the time and
date are the time and date that the
alarm was acknowledged and 29-041 is
the address. The System then displays
the next alarm to acknowledge.
To skip an alarm shown, press NEXT.
The System displays the next alarm in
the series. When the System has
displayed all of the unacknowledged
alarms, it returns to the first Acknowl-
edge menu:
Acknowledge: Alarm Supervisry
