1-32
Description
The PL864-25S card supervises strobe
power with a relay that gives a contact
closure. The relay contact connects to
the OCC-1, terminals 15 and 16, on the
OMM position dedicated to the PLC-4.
The system announces a failure as a
strobe power loss.
ICP-B6 Intelligent Control Point
The Model ICP-B6 can be used as an
independent, remotely located tele-
phone zone, speaker zone (25V or
70.7V RMS), or notification appliance
circuit (NAC), depending on how it is
configured. It communicates through
the analog loop of the MXL System.
ICP-B6 Intelligent Control Point
