Siemens Cerberus PYROTRONICS MXL User Manual

3-39
Operation
ID voltages for module 3
1-ND 2-2.00 3-ND 4-ND ...
11-OVER 12-ND 13-ND 14-ND ...
21-ND 22-ND 23-ND 24-ND ...
31-ND 32-ND 33-ND 34-ND ...
41-ND 42-ND 43-ND 44-ND ...
51-ND 52-ND 53-ND 54-ND ...
When you select ID2, the System
prints the second ID voltages for all
devices assigned to the XLD-1 in a
format similar to the following. (ND =
No Device; OVER = Device reading
over maximum. OVER usually occurs
when the device has been assigned by
CSG-M but no device is present.)
2nd ID voltages for module 3
1-ND 2-0.00 3-ND 4-ND ...
11-OVER 12-ND 13-ND 14-ND ...
21-ND 22-ND 23-ND 24-ND ...
31-ND 32-ND 33-ND 34-ND ...
41-ND 42-ND 43-ND 44-ND ...
51-ND 52-ND 53-ND 54-ND ...
List: Temp
Use List Temp to display the current
temperature on the LCD display at the
location where the detector is installed.
The System as you for a module and
device number:
Type In Module & Device: -
Type the three-digit module number
and three-digit device number using the
numeric keypad and press ENTER.
If the device is not installed or is not
and FP-11 or FPT-11, the system
displays the following message:
Not Applicable or No Device:
If the device is an FP-11 or FPT-11, the
temperature is displayed in the follow-
ing format:
001-001 25 DEG C / 77 DEG F
Press NEXT to display the temperature
of the FP-11 or FPT-11 at the next
higher address in the same loop.
To leave the Temp menu without
going through all subaddresses, press
the Up arrow (
Ù) key. The System
displays the List menu.
List: Mod_type
Use List Mod_type to show the type
of a particular module.
To display the module type of one
module, press ENTER to select
Mod_type. The System asks you for a
module number:
Type In Module Number:
Type the three-digit module number
using the numeric keypad and press
ENTER. The System displays the
module type for the module number
specified:
MOD 074 TYPE: CZM4
If you press NEXT, the System displays
the module type for the next module
number in the sequence:
MOD 075 TYPE: ALD
NOTE: If you enter a module number
not assigned in CSG-M, the System
displays:
No Mod Assigned
With each press of NEXT, the System
continues to display module types
through number 253, the highest
module number allowed by the Sys-
tem. It then returns to the List menu.
