3-42
Operation
List: Output_states
Use List Output States to show the
current states of individual outputs in
the MXL.
To display the output states of one
device, press ENTER to select
Output_states. The System asks you
for a module and device number:
Type In Module & Device: -
Type the three-digit module number
and three-digit device number using
the numeric keypad and press ENTER.
The System displays the output state
of the device specified.
Press NEXT to display the address and
output state of each succeeding device.
When the System has shown the
output states for all devices at that
address, it returns to the List menu.
To leave the Output_states menu
without going through all subad-
dresses, press the Up arrow
(Ù) key.
The System displays the List menu.
To print the device output state
(ON/OFF) of devices assigned to a
specified module, press PRINT when
the O in Output_states is blinking.
The System then asks for a module
number:
Type in Module Number:
Type the three-digit module number
and press ENTER.
NOTE: ALD-2I modules have two
sequential module numbersone for
each loop. XLD-1 modules have four
sequential module numbersone
number for each analog loop.
The System prints the output state of
all the devices for the specified module
in a format similar to the following:
Listing of Output States for Module 3 (OCC-1):
1-ZAC-30 Amplifier Zo: OFF 2-ZAC-30 Ampli...
3-ZAC-30 Amplifier Zo: OFF 4-ZAC-30 Ampli...
5-ZAC-30 Amplifier Zo: OFF 6-ZAC-30 Ampli...
7-ZAC-30 Amplifier Zo: OFF 8-ZAC-30 Ampli...
9-ZAC-30 Amplifier Zo: OFF 10-ZAC-30 Ampli...
11-ZAC-30 Amplifier Zo: OFF 12-ZAC-30 Ampli...
13-ZAC-30 Amplifier Zo: OFF 14-ZAC-30 Ampli...
15-ZAC-30 Amplifier Zo: OFF 16-ZAC-30 Ampli...
17-ZC1-8 Audio Zone Ca: OFF 18-ZC1-8 Audio...
19-ZC1-8 Audio Zone Ca: OFF 20-ZC1-8 Audio...
List: Dev_usages
Use List Dev_usages to show the uses
of individual devices as programmed in
the CSG-M.
To display the usage of one device,
press ENTER to select Dev_usages.
The System asks you for a module and
device number:
Type In Module & Device: -
Type the three-digit module number
and three-digit device number using
the numeric keypad and press ENTER.
The System displays the use of the
device specified (i.e., Alarm, Trouble,
or Status):
069-001 [usage]
Press NEXT to display the address and
use of each succeeding device. When
the System has shown the uses of all
devices at that address, it returns to
the List menu.
