Operation
To print the analog loops current
readings in percent/ft obscuration,
press PRINT when the P in Percent/ft
is blinking. The System asks you for a
module number.
Type In Module Number:
Type the three-digit module number
using the numeric keypad and press
ENTER. The System shows the
following menu for that device (the S
in Senstvty will be blinking):
001-001 Senstvty Pre-alarm Analog
The System prints either the Sensitiv-
ity, Pre-alarm, or Analog readings of all
the devices for the specified module in
a format similar to the following (ND =
No Device):
%/ft sensitivities for module 1
1-3.00 2-NA 3-1.4 4-3.1 ...
11-ND 12-ND 13-ND 14-ND ...
21-ND 22-ND 23-ND 24-ND ...
31-ND 32-ND 33-ND 34-ND ...
41-ND 42-ND 43-ND 44-ND ...
51-ND 52-ND 53-ND 54-ND ...
List: ASD_apps
Use List ASD_apps to display operational
characteristics of the ASD devices.
To display the operational charac-
teristics of one device, press ENTER
to select ASD_apps. The System asks
you for a module and device number:
Type In Module & Device: -
Type the three-digit module number
and three-digit device number using
the numeric keypad and press ENTER.
The System displays the currently
assigned application for the device
specified. (Refer to the chart in Appen-
dix I- Application Specific Detection.)
Press NEXT to display the address and
assigned application of each succeed-
ing device. The System will exit the
ASD_Apps menu if there are no more
ASD devices in that module.
To print the operational characteris-
tics of the ASD devices assigned to
an ALD Loop, press PRINT when the
A in ASD_Apps is blinking. The Sys-
tem asks you for a module number:
Type In Module Number:
Type the three-digit module number
using the numeric keypad and press
ENTER. The System prints a list of all
the applications currently assigned to
all the ASD devices in that ALD loop in
a format similar to the following (ND =
No Device):
ASD Applications for module 1
1-NONE 2-PARK 3-ND 4-OFFC ...
11-ND 12-ND 13-ND 14-ND ...
21-ND 22-ND 23-ND 24-ND ...
31-ND 32-ND 33-ND 34-ND ...
41-ND 42-ND 43-ND 44-ND ...
51-ND 52-ND 53-ND 54-ND ...
List: Disarmed_state
Use List Disarmed_state to show the
alarm state of a currently disarmed
device.
To display the alarm state of one
module, press ENTER to select
Disarmed_state. The System displays
the following:
In Stat Out Stat
Choose either Input Status or Output
Status. The System then asks you for
a module number:
