K-4
Appendix K
Trouble Message The Probable Cause Is:
Device LED Turned On A device LED was turned on from the
Test menu of the MXL.
Device Multiple Response Two or more analog devices at the
same address have reported during
normal supervision.
Device Out of Calibration This message is used with XLD and is
the same as the XL-3 message,
Response out of window at cal.
Device Receive Error An analog device reports this trouble
if it receives an incorrect analog
transmission.
DMC-1 In Record Mode The DMC-1 digital message unit is
recording its message.
DMC-1 Tone Trouble DMC-1 supervisory tone has failed.
Replace the DMC-1 Module.
DMC-1 Phrase Trouble The CSG-M has a non-specified phrase.
Reconfigure the CSG-M.
DMU 1 Failure These messages will be displayed if
DMU 2 Failure the DV-100 message unit activates a
trouble causing TRI module, which is
programmed in the ACM network
menu for a DMU trouble module
address.
Event log 80% full Use extract history in CSG-M to reset
the MXL history log.
Event log 90% full Use extract history in CSG-M to reset
the MXL history log.
Function Recursion Trouble The number of evaluations of output
logic required until outputs are stable
has exceeded the system maximum.
Rewrite CSG-M to simplify functions.
Generic Input Terminal Device being monitored by this OCC-1
input is in a fault condition.
