Siemens Climatix Series User Manual

198 / 244
Siemens Standard application AHU CE1P3977en_02
Building Technologies HMI 01.02.2010
Main Index > Unit > Temp control
Parameter Function Value range Unit Standard R S Link
El heating 2 Actual Value;Jumpline for Electrical heating
2 settings
0…100% % 6
Cooling 2 Actual Value;Jumpline for Cooling 2 settings 0…100% % 6
Fan heating Actual Value;Jumpline for Fan Heating
settings
0…100% % 6
Fan cooling Actual Value;Jumpline for Fan Cooling
settings
0…100% % 6
Fan compensation Actual Value;Jumpline for Fan Temperaure
compensation settings
0…100% % 6
17.15.2 Temperature setpoints
Main Index > Unit > Temp control > Tmp setpoints
Parameter Function Value range Unit Standard R S Link
Act controlled tmp Actual controlled Temperature for Sequence
Value.
Room
Exhaust
Supply
-64.0…64.0
°C
Supply X
X
Act cooling stpt Calculated Cooling Setpoint for controlling -64.0…64.0 °C x
Act heating stpt Calculated Heating Setpoint for controlling -64.0…64.0 °C x
Act sply clg stpt Calculated Cooling Supply Setpoint for
cascade controlling
-64.0…64.0 °C x
Act sply htg stpt Calculated Heating Supply Setpoint for
cascade controlling
-64.0…64.0 °C x
External setpoint Actual external Setpoint according to the
selected function (shifting or override)
-64.0…64.0 °C -5.0
Sply air comp compensation for Supply Temperature
Setpoint in case of Temperature control
Mode Room Supply Cascade in Winter and
Supply in Summer
-10.0…10.0 °C -2.0 4
Comfort setpoint Comfort Basic Setpoint (visible according to
tmp stpt selection)
-64.0…64.0 °C 21.0 6 Section:
5.5.2
Comfort cooling Comfort Setpoint Cooling (visible according
to tmp stpt selection)
-64.0…64.0 °C 22.0 6
Comfort heating Comfort Setpoint Heating (visible according
to tmp stpt selection)
-64.0…64.0 °C 20.0 6
Comfort deadzone Comfort Deadzone (visible according to tmp
stpt selection)
-64.0…64.0 °C 2.0 6
Economy setpoint Economy Basic Setpoint (visible according
to tmp stpt selection)
-64.0…64.0 °C 21.0 6
Economy cooling Economy Setpoint Cooling (visible
according to tmp stpt selection)
-64.0…64.0 °C 24.0 6
Economy heating Economy Setpoint Heating (visible
according to tmp stpt selection)
-64.0…64.0 °C 18.0 6
Economy deadzone Economy Deadzone (visible according to
tmp stpt selection)
-64.0…64.0 °C 6.0 6
Extra Seq setpoint Extra Setpoint Vaue (only visible if Extra-
Htg or ElHtg or Clg as Stand alone
selected)
-64.0…64.0 °C 20.0 6
Supply tmp min stpt Minimum allowed Supply Temperature for
Supply MinMax controlling (only visible with
Temperature control Mode Room or
Exhaust and Supply Sensor)
-15.0…MaxStpt °C 17.0 6
Supply tmp max stpt
Maximum allowed Supply Temperature for
Supply MinMax controlling (only visible with
Temperature control Mode Room or
Exhaust and Supply Sensor)
MinStpt…50.0 °C 27.0 6
Supply tmp min stpt
Minimum allowed Supply Temperature for
Cascade controlling
-64.0…99.0 °C 17.0 6
Supply tmp max stpt
Maximum allowed Supply Temperature for
Cascade controlling
-64.0…99.0 °C 27.0 6
Draught htg max dev Room Flow Limit Heating Max deviation
Shift the maximum allowed Supply
Temperature according to the Supply-
Room or Exhaust deviation (only possible
with cascade controlling)
0.0…64.0 °C 2.0 6
Section:
5.5.2
Basis Document Siemens Climatix Control System
BDCX.100820.01GB
Page 198
