Siemens Climatix Series User Manual

227 / 244
Siemens Standard application AHU CE1P3977en_02
Building Technologies Alarming 01.02.2010
Alarm text Notification
class / group
Alarm no.
room unit
Settings 1 Settings 2
Hrec damper 2/B 45 Time delay 0 s
Sply air hum rel 2/B 46 High Limit 100% rel Time delay 0s
Sply hum deviation 2/B 46
Max deviation = 5.0 %rel
Min Limit = 10.0 %rel
StrtUpDly 60 s
Time delay 3600s
Outs air hum rel 2/B 47 High Limit 100 % rel Time delay 0s
Room hum deviation 2/B 48
Max deviation = 10.0 %rel
Min Limit = 10.0 %rel
StrtUpDly 60 s
Time delay 3600 s
Room humidity rel 2/B 48 High Limit 100 % rel Time delay 0s
Air quality 2/B 49 High Limit 3000 ppm Time delay 0s
Supply air temp 1/A 60 Time delay 0s
Exhaust air temp 2/B 61 Time delay 0s
El htg alarm 1/A 62 Time delay 0s
El heating 2 alarm 1/A 63 Time delay 0s
Fire damper closed 1/A 64 Start delay = Closing Time * 1,15 Time delay 5s
Fire damper no move 1/A 64 Time delay 5s
Fire damper opened 1/A 64 Start delay = Opening Time * 1,15 Time delay 5s
Extr air dmper fdbk 1/A 65 StrtUpDly 180 s Time delay 5s
Outs air dampr fdbk 1/A 65 StrtUpDly 180 s Time delay 5s
Fan alarm 1/A 66 Time delay 0s
Supply fan alarm 1/A 66 Time delay 0s
Supply fan fdbk 1/A 66 StrtUpDly 60 s Time delay 5s
Exhaust fan alarm 1/A 67 Time delay 0s
Exhaust fan fdbk 1/A 67 StrtUpDly 30 s Time delay 5s
Dew point 0/A 68 Time delay 0 s
Sply fan deviation 0/A 69 StrtUpDly 180 s Time delay 60 s
Supply air flow 0/A 69 High Limit 40000 l/s Time delay 10s
Supply air pressure 0/A 69 High Limit 5000 Pa Time delay 10s
Exh fan deviation 0/A 70 StrtUpDly 180 s Time delay 60 s
Exhaust air flow 0/A 70 High Limit 20000 l/s Time delay 10s
Exhaust air press 0/A 70 High Limit 5000 Pa Time delay 10s
Exh tmp fire alarm 1/A 81 Limit 50 °C Time delay 2s
Supply tmp fire alm 1/A 81 Limit 70 °C Time delay 2s
Fire alarm 0/A 81 Time delay 0s
Heating frost tmp 1/A 82 Low Limit 5.0 °C Time delay 0s
Hrec water tmp 1/A 83 Low Limit -2.0 °C Time delay 0s
Heating 2 frost tmp 1/A 84 Low Limit 5.0 °C Time delay 0s
Htg frost monitor 1/A 85 Time delay 0s
Htg 2 frost monitor 1/A 86 Time delay 0s
Hrec frost monitor 1/A 87 Time delay 1200s
Hrec frost pressure 1/A 87 High Limit 5000 Pa Time delay 0s
Conf alm htg 2 0/not Exist Time delay 0 s
Doubled config IO 0/not Exist Time delay 0 s
Not config IO 0/not Exist Time delay 0 s
IO extension module 0/A Time delay 0 s
Basis Document Siemens Climatix Control System
BDCX.100820.01GB
Page 227

Siemens Climatix Series Specifications

General

Application	HVAC control
Communication Protocols	BACnet, Modbus, KNX
Inputs	Analog and digital inputs
Outputs	Analog and digital outputs
User Interface	web interface
Power Supply	24 V AC
Protection Class	IP20
Mounting	DIN rail mounting
