Siemens Climatix Series User Manual

228 / 244
Siemens Standard application AHU CE1P3977en_02
Building Technologies Alarming 01.02.2010
19.6.2 Alphabetically (Alarm names)
Alarm Text Notification
class / group
Alarm no.
room unit
Settings 1 Settings 2
Air quality 2/B 49 High Limit 3000 ppm Time delay 0s
Aux Alarm 2/B 21 Time delay 0s
Auxiliary tmp 2/B 31 Time delay 0s
Communication test 3/C 1 Time delay 600 s
Conf alm htg 2 0/not Exist Time delay 0 s
Cooling 2 DX alarm 2/B 35 Time delay 0s
Cooling 2 DX fdbk 2/B 35 StrtUpDly 10 s Time delay 5s
Cooling 2 pump alm 2/B 35 StrtUpDly 30 s Time delay 1s
Cooling 2 pump fdbk 2/B 35 Time delay 0s
Cooling DX alarm 2/B 41 Time delay 0s
Cooling DX fdbk 2/B 41 StrtUpDly 30 s Time delay 1s
Cooling pump alarm 2/B 41 Time delay 0s
Cooling pump fdbk 2/B 41 StrtUpDly 10 s Time delay 5s
Dew point 0/A 68 Time delay 0 s
Doubled config IO 0/not Exist Time delay 0 s
El heating 2 alarm 1/A 63 Time delay 0s
El htg alarm 1/A 62 Time delay 0s
Exh fan deviation 0/A 70 StrtUpDly 180 s Time delay 60 s
Exh filter alarm 2/B 39 Time delay 0s
Exh tmp fire alarm 1/A 81 Limit 50 °C Time delay 2s
Exhaust air flow 0/A 70 High Limit 20000 l/s Time delay 10s
Exhaust air press 0/A 70 High Limit 5000 Pa Time delay 10s
Exhaust air temp 2/B 61 Time delay 0s
Exhaust fan alarm 1/A 67 Time delay 0s
Exhaust fan fdbk 1/A 67 StrtUpDly 30 s Time delay 5s
External setpoint 2/B 20
High Limit 6.0 °C
Low Limit -6.0 °C
Time delay 5s
Extr air dmper fdbk 1/A 65 StrtUpDly 180 s Time delay 5s
Extract air tmp 2/B 28 Low Limit -10.0 °C Time delay 0s
Fan alarm 1/A 66 Time delay 0s
Fan op hours alarm 2/B 40 Alarm Lim Op hours 17520 h Time delay 0 s
Filter alarm 2/B 39 Time delay 0s
Fire alarm 0/A 81 Time delay 0s
Fire damper closed 1/A 64 Start delay = Closing Time * 1,15 Time delay 5s
Fire damper no move 1/A 64 Time delay 5s
Fire damper opened 1/A 64 Start delay = Opening Time * 1,15 Time delay 5s
Heat recovery alarm 2/B 42 Time delay 0s
Heating 2 frost tmp 1/A 84 Low Limit 5.0 °C Time delay 0s
Heating 2 pump alm 2/B 36 Time delay 0s
Heating 2 pump fdbk 2/B 36 StrtUpDly 10 s Time delay 0s
Heating frost tmp 1/A 82 Low Limit 5.0 °C Time delay 0s
Hrec damper 2/B 45 Time delay 0 s
Hrec efficiency 2/B 44 Time delay 600s
Hrec frost monitor 1/A 87 Time delay 1200s
Hrec frost pressure 1/A 87 High Limit 5000 Pa Time delay 0s
Hrec pump alarm 2/B 43 Time delay 0s
Basis Document Siemens Climatix Control System
BDCX.100820.01GB
Page 228

Siemens Climatix Series Specifications

General

Application	HVAC control
Communication Protocols	BACnet, Modbus, KNX
Inputs	Analog and digital inputs
Outputs	Analog and digital outputs
User Interface	web interface
Power Supply	24 V AC
Protection Class	IP20
Mounting	DIN rail mounting
